T300 Countertop
All Payment Options & High Performance With Printer
T300 Countertop Terminal is a powerful payment device can handle various payment transactions like credit card, debit card, EMV, loyalty, installment, contactless payment and QR code payment in a single terminal.
Core Features
• ARM® Cortex® 500MHz secure processor
• 2.8″ LCD color large display
• Support EMV Chip and PIN (PCI PTS 5.x certified)
• Support MagStripe and contactless payment
• Support QR base application
• Communication interface with USB OTG & RS232
• Fast thermal printer
• Min. 2600mAh large capacity battery
• Wide keypad
Optional
• Built-in contactless reader
• Resistive touch screen
• GPRS or 3G WCDMA communication, WIFI/Bluetooth® V4.x, Ethernet and dialup modem
• Dual SIM support
• Camera for barcode and QR code
• GPS
• Customize standpole
Specifications
Processor
ARM® Cortex® 500MHz secure processor
Display
2.8″ LCD color display, 320 x 240
Resistive touch screen & signature pad (optional)
Reader
Magnetic Track 1/2/3
EMV
Contactless (optional)
QR code payment
Memory
64MB RAM
128/512MB Flash
Keys
20
Camera
(optional)
Card Slots
SAM x max. 2 (optional)
SIM x max. 2 (optional)
Thermal Printer
Printing speed: 30lines/sec
Paper roll: 40mm diameter
Communication Interface
Dial-up modem, Ethernet Optional: GPRS, GPS, 3G WCDMA, WIFI, Bluetooth®
Peripheral
RS232 x max. 2
USB OTG x 1
Audio synthesizer
(optional)
Battery
Min. 2600mAh rechargeable battery
Power supply
DC 9V 1A
Certifications
PCI PTS 5.X
Visa PayWave
American Express ExpressPay
CUP QuickPass
JCB J/Speedy
TQM
EMV L1 & L2
MasterCard Contactless
SRED
QPBOC
FCC/CE
Operating temperature
0 – 45ºC
Storage temperature
-20 – 70ºC
Operating humidity
5 – 95% non-condense
Dimensions & weight
165 (L) x 80 (W) x 63 (H) mm
360g (with battery)
T1000 Countertop
Unprecedented Security & Support Multimedia Promotion
T1000 Countertop combining the powerful 32-bit ARM® 9 CPU assures fast and reliable payment from credit and PIN-based debit to EMV smart cards transactions, meeting the future industry standard with PCI PTS 4.X certification. It is designed with light weight for handheld.
Highly Secure and Reliable
Meeting the future industry standard with PCI PTS 4.X certification, and highly secure and reliable with international certifications (EMV Level 1 & 2, Visa PayWave, MasterCard PayPass, TQM, PBOC and FCC/CE/CCC).
Optional
• Built-in contactless reader
• 1D or 2D barcode reader
• 2.8” LCD color large display
• Touch screen display
• Camera
• GSM/GPRS, 3G/WCDMA and WIFI wireless module
• Audio synthesizer with built-in speaker
• Large paper roll housing
Specifications
Processor
ARM® Cortex® 500MHz secure processor
Display
2.8″ LCD color display, 320 x 240
Resistive touch screen & signature pad (optional)
Reader
Magnetic Track 1/2/3
EMV
Contactless (optional)
QR code payment
Memory
64MB RAM
128/512MB Flash
Keys
20
Camera
(optional)
Card Slots
SAM x max. 2 (optional)
SIM x max. 2 (optional)
Thermal Printer
Printing speed: 30lines/sec
Paper roll: 40mm diameter
Communication Interface
Dial-up modem, Ethernet Optional: GPRS, GPS, 3G WCDMA, WIFI, Bluetooth®
Peripheral
RS232 x max. 2
USB OTG x 1
Audio synthesizer
(optional)
Battery
Min. 2600mAh rechargeable battery
Power supply
DC 9V 1A
Certifications
PCI PTS 5.X
Visa PayWave
American Express ExpressPay
CUP QuickPass
JCB J/Speedy
TQM
EMV L1 & L2
MasterCard Contactless
SRED
QPBOC
FCC/CE
Operating temperature
0 – 45ºC
Storage temperature
-20 – 70ºC
Operating humidity
5 – 95% non-condense
Dimensions & weight
165 (L) x 80 (W) x 63 (H) mm
360g (with battery)
T1000 Countertop
Unprecedented Security & Support Multimedia Promotion
T1000 Countertop combining the powerful 32-bit ARM® 9 CPU assures fast and reliable payment from credit and PIN-based debit to EMV smart cards transactions, meeting the future industry standard with PCI PTS 4.X certification. It is designed with light weight for handheld.
Core Features
• ARM® Cortex® 500MHz secure processor
• 2.8″ LCD color large display
• Support EMV Chip and PIN (PCI PTS 5.x certified)
• Support MagStripe and contactless payment
• Support QR base application
• Communication interface with USB OTG & RS232
• Fast thermal printer
• Min. 2600mAh large capacity battery
• Wide keypad
Optional
• Built-in contactless reader
• Resistive touch screen
• GPRS or 3G WCDMA communication, WIFI/Bluetooth® V4.x, Ethernet and dialup modem
• Dual SIM support
• Camera for barcode and QR code
• GPS
• Customize standpole
Specifications
Toggle content goes here, click edit button to change this text.
T300
Intelligent Docking
QR Code Payment & Charge
SPECTRA T300 with intelligent docking allows seamless ECR linkage which perfectly fits different payment environments. It neatly manages peripherals without sacrificing the mobility of the T300 POS terminal and thoughtfully combines optical technology with mechanical design to enhance QR payment experiences. It is an ideal solution for payment applications in retail, catering and hotel environments.
Features
• ARM® Cortex® A5 secure processor
• 2.8” LCD color resistive touch screen
• 64MB RAM, 512MB Flash
• Supports EMV Chip & PIN (PCI PTS 5.x certified)
• Supports Magstripe & Contactless payments
• Supports QR base applications
• 3G with Dual SIM
• Modem 56kbps & Ethernet 100BaseT interface via Bluetooth® or IR communications interfaces
• Fast thermal printer
Optional
• Mirror at front of docking unit reflected QR code reading by handset
Specifications
Handset
Processor
ARM® Cortex® 500MHz secure processor
Display
2.8″ LCD color display (320 x 240)
Resistive touch screen & signature pad (optional)
Payment acceptance types
Magnetic track 1/2/3
EMV
QR code base application
NFC Contactless
Memory
64MB RAM, 512 / 128 MB Flash
Keys
20
Camera
(optional)
Card Slots
SAM x max. 2 (optional)
SIM x max. 2 (optional)
Thermal Printer
Printing speed: 30lines/sec
Paper roll: 40mm diameter
Communication Interface
Optional: GPRS/3G WCDMA
Wifi / Bluetooth®, GPS
Audio
(optional)
Battery
Min. 2600mAh rechargeable battery
Power supply
Min. 9V for handset
Operating temperature
0-45ºC
Storage temperature
-20-70ºC
Operating humidity
5 – 95% non-condense
Certifications
PCI PTS 5.X
EMV L1 & L2
Visa PayWave
MasterCard Contactless
JCB J/Speedy
American Express ExpressPay
CUP QuickPass
SRED
PURE
TQM
FCC/CE
Intelligent Docking
Communication interfaces
Dial-up modem
100baseT Ethernet
USB host x 1
USB slave x 1
Peripheral
RS232 x max. 2
Others
On/Off Switch x 1
LED indicator x 1
Contact pins for handset charging
Power Input
DC 9.5V 1A
Weight & Dimension
Docking with mirror only:
221(L)x86(W)x69(H)mm, 252g
Handset & Docking:
21(L)x86(W)x106(H)mm, 570g
Docking without mirror only:
162(L)x79(W)x43(H)mm, 170g
Handset & Docking:
170(L)x 81(W)x81(H)mm, 488g
T300 Countertop
All Payment Options & High Performance With Printer
T300 Countertop Terminal is a powerful payment device can handle various payment transactions like credit card, debit card, EMV, loyalty, installment, contactless payment and QR code payment in a single terminal.
Core Features
• ARM® Cortex® 500MHz secure processor
• 2.8″ LCD color large display
• Support EMV Chip and PIN (PCI PTS 5.x certified)
• Support MagStripe and contactless payment
• Support QR base application
• Communication interface with USB OTG & RS232
• Fast thermal printer
• Min. 2600mAh large capacity battery
• Wide keypad
Optional
• Built-in contactless reader
• Resistive touch screen
• GPRS or 3G WCDMA communication, WIFI/Bluetooth® V4.x, Ethernet and dialup modem
• Dual SIM support
• Camera for barcode and QR code
• GPS
• Customize standpole
Specifications
Toggle content goes here, click edit button to change this text.
T1000 Countertop
Unprecedented Security & Support Multimedia Promotion
T1000 Countertop combining the powerful 32-bit ARM® 9 CPU assures fast and reliable payment from credit and PIN-based debit to EMV smart cards transactions, meeting the future industry standard with PCI PTS 4.X certification. It is designed with light weight for handheld.
Highly Secure and Reliable
Meeting the future industry standard with PCI PTS 4.X certification, and highly secure and reliable with international certifications (EMV Level 1 & 2, Visa PayWave, MasterCard PayPass, TQM, PBOC and FCC/CE/CCC).
Optional
• Built-in contactless reader
• 1D or 2D barcode reader
• 2.8” LCD color large display
• Touch screen display
• Camera
• GSM/GPRS, 3G/WCDMA and WIFI wireless module
• Audio synthesizer with built-in speaker
• Large paper roll housing
Specifications
Toggle content goes here, click edit button to change this text.
T300 Unattended Payment Terminal
Perfectly fit for self-service solutions
T300 Unattended is one of just a few payment terminals in the market that meets all of the prerequisites to be endorsed as a truly “unattended” unit. It is also certified for use in the outdoor environments, in both heat and cold, and is water and dust resistant. Like all of SPECTRA’s devices, it is built to perform as expected… and last. To ensure customer satisfaction, we work with you to integrate it into your unique retail environment. This sturdy little device pairs perfectly with kiosks, ticketing centers, self- service stores, and vending machines. Our goal: to increase transaction efficiency and deliver a hassle-free customer experience.
Core Features
• Support Magnetic, Smart Card and NFC card
• Generate dynamic QR code
• High performance ARM® Cortex® secure processor
• Large TFT LCD color display
• Built-in MDB interface connect with vending machine controller
• IP54 protection from dust ingress and wet working environment
• Support Ethernet, 3G WCDMA, 4G & Bluetooth®
• USB OTG interface
• PCI 5.X
Optional
• Touch screen
• Front camera
• WIFI
• Ethernet
All-in-one Unattended POS
SPECTRA’s T300 Unattended Payment Terminal offers a robust set of payment features, is operationally reliable in totally unattended environments, and comes housed in a durable, long-lasting case.
Specifications
Specifications
Processor
ARM® Cortex®
Display
2.8″ TFT LCD color display (320 x 240)
Touch screen & signature pad (optional)
Reader
Magnetic stripe card
Chip card (EMV)
QR code
NFC Contactless card
Memory
64MB RAM
128/512MB Flash
Keys
15 or no keypad (optional)
Peripheral
RS232 x 1
MDB slave x 1
OTG USB x 1
Card slots
SAM x 1 & SIM x 2 OR
SAM x 2 & SIM x 1
Audio
Yes (optional)
Contactless reader
Contactless reader for ISO 14443 A/B
Camera
CMOS camera in front (optional)
Communication interface
Ethernet
3G WCDMA
4G
Bluetooth®
Power supply
DC 9V with DC power socket or MDB power
Certifications
PCI PTS 5.X
Visa PayWave
JCB J/Speedy
CUP QuickPass
PURE
EMV L1 & L2
MasterCard Contactless
American Express ExpressPay
Discover D-PAS
FCC/CE
Operating temperature
-20 – 65ºC
Storage temperature
-20 – 65ºC
Operating humidity
5 – 90% non-condense
Dimensions & weight
171(L) x 124(W) x 68(H)mm, 420g (no camera)
171(L) x 124(W) x 68(H)mm, 440g (with camera)
Cutout size :
190(L) x 132(W) x 22(D)mm (for EVA Frame)
180(L) x 132(W) x 78(D)mm (for VCCS Frame)
APOLLO
Mobile all-in-one Android based POS with API developer support
APOLLO is the first android based terminal at SPECTRA. This smart device position itself is a breakthrough of payment terminals. Besides its all-in-one payment acceptance, APOLLO delivers ultimate hardware capability from software development to custom-made solutions for merchants.
Core Features
• ARM® Cortex® secure processor
• Android module based on Qualcomm Quad-core A7 1.1 GHz
• Large memory with 1GB RAM + 8GB Flash
• Android V7.1 operating system
• 5.5” LCD color display with cap sense multi-touch screen
• Support 1D/2D barcode decode
• 5MP CMOS rear camera with flash light, and 0.3MP CMOS front camera
• Bluetooth® dual mode, WIFI, GPS/GLONASS/BEIDOU
• 4G FDD and TDD/WCDMA/GSM/GPRS
• Support dual SIM
• Min. 5200mAh (dual cell 2600mAh) rechargeable battery
• One user defined shortcut button
Optional
• Fingerprint sensor
• Docking unit
API Developer Support
User friendly Android base platform with API support – flexible development – to enhance the performance under different industries needs.
Specifications
Specifications
Processor
ARM® Cortex® Secure Processor
Qualcomm Quad-core A7 1.1GHz
Display
5.5″ TFT color display, 1280 x 720, 16.7M
Cap sense multi-touch screen, support electronic signature
Reader
Magnetic Track 1/2/3
EMV
NFC Contactless
QR code payment
Operating System
Android V7.1
Memory
1GB RAM + 8GB Flash
2GB RAM + 16GB Flash (optional)
Camera
5MP auto zoom camera with flash light
0.3MP CMOS front camera
Support 1D/2D barcode decode
Card Slots
SAM x 1
Micro SD x 1 (optional)
SIM x 2 (optional)
Thermal Printer
2.25″ Thermal
Printing speed: 18lines/sec
Paper roll: 40mm diameter
Communication Interface
WIFI (single/dual band, direct)
Bluetooth®
GPS/GLONASS/BEIDOU
Dual SIM standby
Internal antennas
2G/3G/4G FDD & TDD
Peripheral
USB OTG x 1 (Type C)
Docking
Optional
Audio
Speaker x 1
Microphone x 1, support voice recording and playback
Battery
Min. 5200mAh (dual cell 2600mAh) rechargeable battery
Power supply
DC9V power adaptor, 2A USB charger
Keys
On/off, Vol up/down, one shortcut key
Certifications
PCI PTS 5.X
Visa PayWave
American Express ExpressPay
JCB J/Speedy
TQM
MCCS Contactless Acceptance Device Type Approval
EMV L1 & L2
MasterCard Contactless
SRED
QPBOC
FCC/CE
VCCS Contactless Kernel Type Approval
Operating temperature
0 – 45ºC
Storage temperature
-20 – 70ºC
Operating humidity
5 – 95% non-condense
Dimensions & weight
180 (L) x 84 (W) x 61 (H) mm
450g
T300 Pinpad
All payment options & high performance
T300 Pinpad is compact in size and provides all secure payment options for EMV chip, swipe and contactless payment. It is designed to integrate with most POS terminals or cash registers in the retail environment.
Optional
• Resistive touch screen
• Built-in contactless reader
Core Features
• ARM® Cortex® 500MHz secure processor
• 2.8” LCD color large display
• Support EMV Chip & PIN (PCI PTS V4.x certified)
• Support Magstripe and contactless payment
• Wide keypad
Specifications
Processor
ARM® Cortex® 500MHz secure processor
Display
2.8″ LCD color display, 320 x 240
Touch screen & signature pad (optional)
Reader
Magnetic Track 1/2/3
EMV
NFC Contactless
Memory
64MB RAM
128/512MB Flash
Keys
20
Card slots
SAM x max. 2
Communication interface
Ethernet
Peripheral
RS232 x 1
USB x 1 device
Power supply
DC 5V 1A
Audio synthesizer
Optional
Certifications
PCI PTS
Visa PayWave
American Express ExpressPay
CUP QuickPass
JCB J/Speedy
TQM
EMV L1 & L2
MasterCard Contactless
SRED
QPBOC
FCC/CE
Operating temperature
0 – 45ºC
Storage temperature
-20 – 70ºC
Operating humidity
5 – 95% non-condense
Dimensions & weight
132 (L) x 80 (W) x 32 (H) mm
210g
SP530 Pinpad
Compact & handy POS with high security
SP530 Pinpad supports iOS/Android connection to pair a smart phone, tablets or PDA for mobile payments. It offers the latest PCI PTS V4.0 security, EMV Level 1 & 2, EMV Contactless L1 certification which brings high security and reliable performance to process a variety of transactions.
Core Features
• High performance ARM® Cortex® secure CPU
• Clear display with white LED backlight
• Smart card reader and magnetic card reader
• Suitable for POS system, payment terminals, desktop terminals and cash register systems integration
Optional
• NFC/contactless reader for EMV, Visa payWave, Mastercard Contactless
• Micro SD interface
Benefits
• Light and compact design
• Suitable for desktop terminals and cash register systems integration
• Ideal for any size of retailers to integrated with existing POS system or payment terminals
Specifications
Processor
ARM® Cortex® secure processor
Display
LCD Monochrome, 128 x 64
Reader
Triple track bidirectional MSR
EMV Contact
NFC Contactless
Memory
256KB RAM
8/16MB Flash
Card Slots
SAM x 1 (optional)
Micro SD x 1 (optional)
Keys
16
Buzzer
A single tone beeper
Cable Connection
Spiral cable with USB plug (type A) or RS232 (serial RJ11/DB9)
Power supply
DC 5V from spiral cable
Certifications
PCI PTS 4.x with SRED
Visa payWave
CUP QuickPass
PURE
EMV contact L1 & L2
EMV contactless L1
Mastercard Contactless
Mastercard TQM
Operating temperature
0 – 45ºC
Storage temperature
-20 – 70ºC
Operating humidity
5 – 95% non-condense
Dimensions & weight
110 (L) x 70 (W) x 36 (H) mm
220g
SR300 Contactless reader with camera
Premium checkout reader suitable for all NFC & QR code payments
The SR300 Contactless Reader with Camera enables the NFC reader a top up function to accept the latest QR code payments application in different industries. It has the powerful 32 bit processor supports various POS and ECR’s in the market. It is a complete contactless and QR payment solution with a compact and modern design that fits the requirements of premier merchants
Core Features
• Supports NFC & QR code payments
• ARM® 32bit processor plus large memory design to cater for different payment card schemes
• Large LCD colour display for clear transaction message support graphic and logo promotion
• Built-in light sensor, adaptive to different ambient brightness
• Support ISO14443 Type A/B
• Accepts all NFC & Mobile payments – Apple Pay, Google Pay, Samsung Pay & QR code payment etc.
• Ideal for merchants who want to expand their business with new trend payment module
Adjustable Stand and QR Reader
User friendly design with up to 180˚ tilts adjustable stand and QR reader is suitable for different scenarios of merchants.
SR300, A Brilliant Check Out Assistant!
SR300 is a great quick check out assistant to POS products to enhance the terminal performance and user experience. It is ideal for merchants who want to expand their business with new trend payment model!
Specifications
Processor
32 bit
Display
Standard version: Mono display, 128 x 64
Camera version: 2.8″ LCD color display, 320 x 240
Reader
NFC Contactless
QR code payment (optional)
Memory
8MB RAM
16MB Flash
Peripheral
RS232 x 1 (optional)
USB x 1 (optional)
Card slots
SAM x max. 3 (optional)
Power supply
DC 5V/9V
Camera
Built-in
Certifications
Visa PayWave
American Express ExpressPay
CUP QuickPass
JCB J/Speedy
TQM
EMV L1 & L2
MasterCard Contactless
QPBOC
FCC/CE/CCC
Operating temperature
0 – 45ºC
Storage temperature
-20 – 70ºC
Operating humidity
5 – 95% non-condense
Dimensions & weight
Standard version (Exclude build-in QR code camera):
143 (L) x 96 (W) x 29.5 (H) mm
260g (without stand), 320g (with stand)
Premium version (Include build-in QR code camera):
195 (L) x 96 (W) x 42 (H) mm
310g (without stand), 370g (with stand)
Specifications
Toggle content goes here, click edit button to change this text.
Optional
• Mirror at front of docking unit reflected QR code reading by handset
Features
• ARM® Cortex® A5 secure processor
• 2.8” LCD color resistive touch screen
• 64MB RAM, 512MB Flash
• Supports EMV Chip & PIN (PCI PTS 5.x certified)
• Supports Magstripe & Contactless payments
• Supports QR base applications
• 3G with Dual SIM
• Modem 56kbps & Ethernet 100BaseT interface via Bluetooth® or IR communications interfaces
• Fast thermal printer
T300
Intelligent Docking
QR Code Payment & Charge
SPECTRA T300 with intelligent docking allows seamless ECR linkage which perfectly fits different payment environments. It neatly manages peripherals without sacrificing the mobility of the T300 POS terminal and thoughtfully combines optical technology with mechanical design to enhance QR payment experiences. It is an ideal solution for payment applications in retail, catering and hotel environments.
Specifications
Toggle content goes here, click edit button to change this text.
Optional
• Built-in contactless reader
• Resistive touch screen
• GPRS or 3G WCDMA communication, WIFI/Bluetooth® V4.x, Ethernet and dialup modem
• Dual SIM support
• Camera for barcode and QR code
• GPS
• Customize standpole
Core Features
• ARM® Cortex® 500MHz secure processor
• 2.8″ LCD color large display
• Support EMV Chip and PIN (PCI PTS 5.x certified)
• Support MagStripe and contactless payment
• Support QR base application
• Communication interface with USB OTG & RS232
• Fast thermal printer
• Min. 2600mAh large capacity battery
• Wide keypad
T1000 Countertop
Unprecedented Security & Support Multimedia Promotion
T1000 Countertop combining the powerful 32-bit ARM® 9 CPU assures fast and reliable payment from credit and PIN-based debit to EMV smart cards transactions, meeting the future industry standard with PCI PTS 4.X certification. It is designed with light weight for handheld.
Highly Secure and Reliable
Meeting the future industry standard with PCI PTS 4.X certification, and highly secure and reliable with international certifications (EMV Level 1 & 2, Visa PayWave, MasterCard PayPass, TQM, PBOC and FCC/CE/CCC).
Optional
• Built-in contactless reader
• 1D or 2D barcode reader
• 2.8” LCD color large display
• Touch screen display
• Camera
• GSM/GPRS, 3G/WCDMA and WIFI wireless module
• Audio synthesizer with built-in speaker
• Large paper roll housing
Specifications
Specifications
Processor
ARM® Cortex® 500MHz secure processor
Display
2.8″ LCD color display, 320 x 240
Touch screen & signature pad (optional)
Reader
Magnetic Track 1/2/3
EMV
Contactless (optional)
Memory
64MB RAM
128/512MB Flash
Keys
20
Audio synthesizer
(Optional)
Card Slots
SAM x max. 2 (optional)
SIM x 2 (optional)
Peripheral
RS232 x 1
USB OTG x 1
Communication Interface
GPRS or 3G WCDMA/GPS(AGPS), WIFI/Bluetooth®
Power supply
DC 5V 1A (USB)
Battery
Min. 2600mAh rechargeable battery
Certifications
PCI PTS
Visa PayWave
American Express ExpressPay
CUP QuickPass
JCB J/Speedy
TQM
EMV L1 & L2
MasterCard Contactless
SRED
QPBOC
FCC/CE
Operating temperature
0 – 45ºC
Storage temperature
-20 – 70ºC
Operating humidity
5 – 95% non-condense
Dimensions & weight
130 (L) x 80 (W) x 40 (H) mm
270g (with battery)
Specifications
Specifications
Processor
ARM® Cortex® 500MHz secure processor
Display
2.8″ LCD color display, 320 x 240
Touch screen & signature pad (optional)
Reader
Magnetic Track 1/2/3
EMV
Contactless (optional)
Memory
64MB RAM
128/512MB Flash
Keys
20
Audio synthesizer
(Optional)
Card Slots
SAM x max. 2 (optional)
SIM x 2 (optional)
Peripheral
RS232 x 1
USB OTG x 1
Communication Interface
GPRS or 3G WCDMA/GPS(AGPS), WIFI/Bluetooth®
Power supply
DC 5V 1A (USB)
Battery
Min. 2600mAh rechargeable battery
Certifications
PCI PTS
Visa PayWave
American Express ExpressPay
CUP QuickPass
JCB J/Speedy
TQM
EMV L1 & L2
MasterCard Contactless
SRED
QPBOC
FCC/CE
Operating temperature
0 – 45ºC
Storage temperature
-20 – 70ºC
Operating humidity
5 – 95% non-condense
Dimensions & weight
130 (L) x 80 (W) x 40 (H) mm
270g (with battery)
Optional
• Resistive touch screen
• Built-in contactless reader
• Dual SIM support
Core Features
• ARM® Cortex® 500MHz secure processor
• 2.8” LCD color large display
• Support EMV Chip & PIN (PCI PTS V4.x certified)
• Support Magstripe and Contactless payment
• GPRS or 3G WCDMA/GPS communication, WIFI/Bluetooth® V4.x
• USB OTG interface
• Large capacity battery
• Wide keypad
T300 mPOS
Portable Terminal with All Payment Options & High Performance
T300 mPOS provides all payment options for MSR, EMV and NFC contactless payment. Featuring with 2.8″ color display (optional touch screen or signature pad) allows broaden applications. Also, it offers flexible wireless connectivity choice of 3G, GPRS, WIFI and Bluetooth® are definitely user-friendly and convenient to the mobile merchants.
Specifications
Display
LCD mono display, 128 x 64
Reader
Magnetic Track 1/2/3
EMV
NFC Contactless (optional)
Memory
256KB RAM
8/16MB Flash
Card Slots
SAM x Max. 1 (optional)
Micro SD x 1 (optional)
Keys
17
Communication Interface
Bluetooth®
Peripheral
USB x 1 device
Power supply
DC 5V, 500mA (USB 2.0)
Battery
480mAh
Certifications
PCI PTS 4.0
Visa PayWave
CUP QuickPass
TQM
FCC/CE/CCC
EMV L1 & L2
MasterCard Contactless
SRED
QPBOC
Operating temperature
0 – 45ºC
Storage temperature
-20 – 70ºC
Operating humidity
5 – 95% non-condense
Dimensions & weight
110 (L) x 70 (W) x 19 (H) mm
140g
Benefits
• Ergonomic and compact design
• Performance suitable for mobile payment
• Simple and user-friendly operation application platform
• Replaceable battery
• Optional NFC contactless reader certified with MasterCard PayPass and Visa PayWave
• Ideal for any retailers to accept mobile payment reliably
Core Features
• High performance ARM® Cortex® secure CPU
• Large display with white LED backlight
• Support EMV Chip & PIN
• Support Magstripe and Contactless payment
• Support iOS/Android base smartphone/tablet/PDA’s payment application via Bluetooth® pairing
• Micro USB 2.0 device port full speed
• 140g ultra light and compact size with stylish design
SP530 mPOS
Compact size & handy POS ideal for any merchants’ need
SP530 mPOS supports iOS/Android connection to pair a smart phone, tablets or PDA for mobile payments. It offers the latest PCI PTS V4.0 security, EMV Level 1 & 2, EMV Contactless L1 certification which brings high security and reliable performance to process a variety of transactions.
